PhosKinTime Documentation

Welcome to the official documentation for PhosKinTime, an ODE-based modeling toolkit for phosphorylation kinetics and transcriptional time-series analysis. This index page provides an overview of each package and submodule in the project.

Acknowledgments

This project began from my master's thesis work in the Theoretical Biophysics group, now the Klipp-Linding Lab, at Humboldt-Universität zu Berlin. The submitted thesis focused on kinopt, while related components of the broader modelling framework were developed in parallel during that period and continued afterwards.

The implemented version of kinopt was developed as the core thesis-stage component. The tfopt and protwise components were developed by me during the same broader project period and subsequent continuation of the work. The networkmodel component was later designed and implemented independently after that period as an extension of the original modelling framework.

The initial distributive, successive, and combinatorial ODE formulations came from the thesis-stage modelling framework, while the saturation model was added independently at a later stage as an extension of the system.

The subpackage tfopt is an optimized and extended derivative of original work by my colleague Julius Normann, adapted with permission.

I am grateful to Ivo Maintz for generous technical support with server access, package experimentation, and computational setup.

Educational notebooks

Executable educational notebooks are available under notebooks/ and cover end-to-end dummy-data workflows for KinOpt, TFOpt, protein-wise ODE fitting, and network-level modeling.

Run them interactively with jupyter lab notebooks/ or as executable tests with pytest --nbmake notebooks/*.ipynb.

No-code dashboard

Use the unified Streamlit dashboard to browse existing result directories, preview uploaded inputs, launch registered CLI/Pixi workflows, and download result archives. See No-code dashboard documentation.

Modeling backends (local vs global)

PhosKinTime provides two complementary modeling stacks:

1) Local phosphorylation ODE models (per protein / per site)
These implement the classic mechanistic hypotheses (distributive, successive, random) and are optimized against phosphoproteomics time series. They are intended for detailed fitting of individual proteins or phosphorylation sites.

2) Global coupled signaling–GRN model (networkmodel)
This is a network-scale ODE system that couples kinase-driven phosphorylation dynamics to TF-mediated transcriptional regulation. It is intended for system-level simulations (e.g., global knockouts, functional influence propagation) and calibration against multi-omics time series.

For the full mathematical specification of the coupled global system (all equations), see: Global model documentation

Package mapping: - kinopt: optimization + post-processing for local phosphorylation models - tfopt: TF→mRNA constrained optimization and reporting - networkmodel: coupled kinase-signaling + GRN simulation and optimization wrappers

Typical workflows: - Local phosphorylation fitting: prep → kinopt → model → sensitivity → plotting - TF regulation fitting: prep → tfopt → reports - Global network simulation: prep → networkmodel → simulate → measure → KO analysis - Global network optimization: prep → networkmodel → optimize → measure → KO analysis

Core Modules

config

• Holds global constants, CLI parsing, and logging setup.

models

• Implements ODE systems for different phosphorylation hypotheses.

paramest

• Parameter estimation routines for ODE models (currently using paramest/normest.py).

steady

• Computes steady-state initial conditions for each model.

sensitivity

• Morris sensitivity analysis for parameter sensitivity.

plotting

• Visualization tools for plotting results.

utils

• Helper functions for data loading, saving, and plotting.

Optimization Frameworks

kinopt

The kinopt package provides advanced optimization and post-processing:

local

Local constrained optimization workflows with compact preprocessing arrays, Numba-accelerated objectives, and notebook examples that demonstrate ranked multistart solution ensembles.

optimality

Post-optimization analysis: feasibility checks, sensitivity reporting, LaTeX table generation, diagnostic plots

fitanalysis

Additional fit-evaluation utilities for residual and performance analysis

tfopt

Originally implemented by Julius Normann.

This version has been modified and optimized by Abhinav Mishra.

The tfopt package estimates transcriptional regulation using mRNA and TF time-series data through constrained optimization.

local

Local constrained optimization for TF-target regulatory effects with α and β constraints, deterministic dummy-data notebooks, CSV exports, and visualization. - Numba-accelerated objectives and notebook-oriented CSV/plot reports

objfn

Shared objective logic and prediction functions for both backends

optcon

Data construction and constraint generation from TF–mRNA interaction files

utils

Input parsing, Excel + plot output, and HTML report generation

Command-Line Entry Point for the Phoskintime Pipeline

The phoskintime pipeline provides a command-line interface to execute various stages of the workflow,
including preprocessing, optimization, and modeling. Below are the usage instructions and examples for running
the pipeline.

Before running any commands, ensure you are in the working directory one level above the project root (where the project
directory is visible).

Run All Stages

Run the entire pipeline with the default (local) solver:

python phoskintime all

Note: The all command runs prep → tfopt → kinopt → model only. It does not invoke the global network simulation (networkmodel). To run the global model, use the separate entry point:

phoskintime-global
# or
python -m networkmodel.runner

The global model requires outputs from kinopt and tfopt as inputs. Run all (or the individual optimization stages) before invoking phoskintime-global.

Run Preprocessing Only

Execute only the preprocessing stage:

python phoskintime prep

Run Transcription-Factor-mRNA Optimization (TFOPT)

Run TFOPT with the local solver:

python phoskintime tfopt --mode local

Run Kinase-Phosphorylation Optimization (KINOPT)

Run KINOPT with the local solver:

python phoskintime kinopt --mode local

Run the Model

Execute the modeling stage:

python phoskintime model

Quick Start: Setting up environment

This guide provides clean setup instructions for running the phoskintime package on a new machine. Choose the scenario that best fits your environment and preferences.

Before proceeding, ensure you have the following prerequisites installed:

• graphviz (for generating diagrams)

# For Debian/Ubuntu
sudo apt-get install graphviz

# For Fedora
sudo dnf install graphviz

# For MacOS
brew install graphviz

• python 3.10 or higher

# Check python version
python3 --version

# If not installed, install python 3.10 or higher

# For Debian/Ubuntu
sudo apt-get install python3.10

# For Fedora
sudo dnf install python3.10

# For MacOS
brew install python@3.10

• git (for cloning the repository)

# For Debian/Ubuntu
sudo apt-get install git

# For Fedora
sudo dnf install git

# For MacOS
brew install git

Scenario 1: pip + virtualenv (Debian/Ubuntu/Fedora)

For Debian/Ubuntu

sudo apt update && sudo apt install -y python3 python3-pip python3-venv git

For Fedora

sudo dnf install -y python3 python3-pip python3-virtualenv git

Setup

git clone git@github.com:bibymaths/phoskintime.git
cd phoskintime

# Create and activate a virtual environment
python3 -m venv venv
source venv/bin/activate

# Install dependencies
pip install --upgrade pip
pip install -r requirements.txt

Scenario 2: Poetry + pyproject.toml

Install Poetry (all platforms)

curl -sSL https://install.python-poetry.org | python3 -
# Or: pip install poetry

Setup

git clone git@github.com:bibymaths/phoskintime.git
cd phoskintime

# Install dependencies
poetry install

# Optional: activate shell within poetry env
poetry shell

Scenario 3: Using uv (fast, isolated pip alternative)

Install uv

curl -LsSf https://astral.sh/uv/install.sh | sh

Setup

git clone git@github.com:bibymaths/phoskintime.git
cd phoskintime

# Create virtual environment and install deps fast
uv venv
source .venv/bin/activate
uv pip install -r requirements.txt

Scenario 4: Conda or Mamba (Anaconda/Miniconda users)

Setup

git clone git@github.com:bibymaths/phoskintime.git
cd phoskintime

# Create and activate conda environment
conda create -n phoskintime python=3.10 -y
conda activate phoskintime

# Install dependencies
pip install -r requirements.txt

Or if using pyproject.toml, add:

pip install poetry
poetry install

For making illustration diagrams, you need to install Graphviz. You can do this via conda or apt-get:

conda install graphviz

or

apt-get install graphviz

or download it from the Graphviz website. For macusers, you can use Homebrew:

brew install graphviz
